GHIBLI 30:1 on trolley - Airless pneumatic anticorrosion spray package

Larius is expert in high pressure industrial spray technology equipment for demanding protective coating airless application.

The Ghibli 30:1 is an high pressure pneumatic spray package, robust and resistant, for industrial painting and protective coating sector that allow the use of a wide range of medium-solid products to dispensed in total efficiency thanks to the  perfect coverage of airless atomisation for finishing large surfaces in a shorter time.

This airless anticorrosion spray unit, Atex certified, thanks to the quality of its construction materials, ensures the absence of pressure drop during the spraying application, a thick and uniform finish and a reduce of overspray.

Read more

Request quote
Compare product Categories: , Tags:
Subscribe to newsletter

Additional information

Version

On trolley
Material

Acciaio al carbonio, Stainless steel
Max. air pressure

7 bar
Max. delivery

3,8 l/min
Max. fluid outlet pressure

210 bar
Air supply inlet

3/8" BSPP (F)
Material inlet

M36X2 (M)
Fluid outlet

1/4″ BSPP (M)
Effective motor diameter

4" 1/4 – 108 mm
Piston stroke

4" – 102 mm
Delivery per cycle

63 cc
Seals material

PTFE + Polietilene
Sound pressure level

<80 dB (A)
Weight

25 Kg

Ghibli 30:1 airless spray pump included air pressure regulator, filter, lubrificator and suction hose with filter.

Pneumatic airless pumps catalogue
  • General industrial finishing
  • Woodworking and finishing
  • Marine & Off-shore
  • Oil & Gas
  • Metal products and machinery
  • Metal and steel protection
  • Plastic finishing
  • Anti-rust
  • Fixatives
  • Base coat
  • Fireproof
  • Intumescents
  • Lacquers
  • Mordants
  • Primer
  • Water / Solvent based products
  • Single or double components protective coating
  • Epoxy resins
  • Vinyl coating
  • Enamels
  • Topcoat
  • Catalysed paints
  • AT250 airless manual spray gun + nozzle holder base – fitting 1/4″ BSPP (M) – nozzle not included Code LA11250
  • AT250 airless manual spray gun + nozzle holder base – fitting 1/4″ NPSM (M) – nozzle not included Code LA11255
  • AT250 airless manual spray gun – fitting 1/4″ BSPP (M) – nozzle holder base and nozzle not included Code LA11240
  • AT250 airless manual spray gun – fitting 1/4″ NPSM (M) –  nozzle holder base and nozzle not included Code LA11256
  • Spray airless gun butt filters 200 mesh – 25 units Code LA11019/25
  • Spray airless gun butt filters 100 mesh – 25 units Code LA11037/25
  • Spray airless gun butt filters 60 mesh – 25 units Code LA11038/25
  • Spray airless gun butt filters 30 mesh – 25 units Code LA11039/25
  • PLA pole airless spray gun fitting 1/4″ BSPP (M) – Max. pressure 250 bar – 130 cm Code LAK11420
  • PLA pole airless spray gun fitting 1/4″ BSPP (M) – Max. pressure 250 bar – 180 cm Code LAK11425
  • PLA pole airless spray gun fitting 1/4″ BSPP (M) – Max. pressure 250 bar – 240 cm Code LAK11430
  • PLA pole airless spray gun fitting 1/4″ BSPP (M) – Max. pressure 450 bar – 130 cm Code LAK11436
  • PLA pole airless spray gun fitting 1/4″ BSPP (M) – Max. pressure 450 bar – 180 cm Code LAK11441
  • PLA pole airless spray gun fitting 1/4″ BSPP(M) – Max. pressure 450 bar – 240 cm  Code LAK11446
  • Manual airless gun extension 30 cm  Code LA153
  • Manual airless gun extension 40 cm  Code LA154
  • Manual airless gun extension 60 cm  Code LA155
  • Manual airless gun extension 80 cm  Code LA158
  • Manual airless gun extension 100 cm Code LA156
  • Super Fast Clean airless nozzles. Sizes from 11-20 to 51-80 Code LASFC
  • Top Spraying Clean airless nozzle. Sizes from 7-10 to 31-60  Code LATSC
  • Standard airless nozzles. Sizes from 7-20 a 51-80
  • Antipulsation airless hose Ø 1/4″ fitting 1/4″ BSPP – 5 m – Max. Pressure 230 bar  Code LA18021
  • Antipulsation airless hose Ø 1/4″ fitting 1/4″ BSPP – 7,5 m – Max. Pressure 230 bar Code LA18022
  • Antipulsation airless hose Ø 1/4″ fitting 1/4″ BSPP – 10 m – Max. Pressure 230 bar  Code LA18025
  • Antipulsation airless hose Ø 1/4″ fitting 1/4″ BSPP – 15 m – Max. Pressure 230 bar  Code LA18024
  • Stainless steel line filter with recirculation – 1/4″ BSPP Code LA98388/1
  • Line filter with recirculation 1/4″ BSPP Code LA96220/1
  • Stainless steel line filter with recirculation – M16X1,5 Code LA98388
  • Filtro di linea con ricircolo – M16X1,5 Code LA96220
  • Stainless steel line filter – M16X1,5 Code LA98387
  • Line filter – M16X1,5  LA96200
  • Heater Code LA6099
  • 6 l gravity tank Code LA94081
